CCG Terminal Junction Box 20mm 4 Way TX Type Glass Reinforced Polyester IP68 118mm OD

Description

Junction Box, 20 mm Entry Size, 4 Number of Entries, 118 mm Outside Diameter, 92 mm Mounting Centres, 80 mm Rail Mounting Centres, 92 mm Distance Between Centres, IP68, -60 to 55 deg C/-60 to 110 deg C, 98 mm Overall Height

Key Specifications

SKU	CCG100301
Brand	CCG
Range Name	Posi-Box
Product Type	Terminal Boxes & Enclosures

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	For hazardous installations High temperature resistance and anti-static properties DIN rail mounting studs are provided for use with terminal blocks Raised domed lid facilitates connections to be made outside of the box Only approved CCG cable glands and non-sparkling terminals must be used Dust and water tight to IP66/68 when fitted with CCG sealed cable glands Boxes can be buried for extended periods
Standard Pack Size	8
UNSPSC Class	39121300
UOM	EA
Vendor Product	100301
Distance Between Centres	92 mm
Entry Size	20 mm
IP Rating	IP68
Mounting Centres	92 mm
Number of Entries	4
Outside Diameter	118 mm
Overall Height	98 mm
Rail Mounting Centres	80 mm
Temperature	-60 to 55 deg C/-60 to 110 deg C
