Solis 4G PV Grid Tie Solar Inverter 2 MPPT 3 Phase 10kW 22/22A

chevron-left

Description

chevron-down
Solar Inverter, 3 Phase, 15 kW DC Input, 1000 Volt DC Input, 600 Volt DC Nominal, 160-850 Volt DC MPPT Voltage Range, 180 Volt DC Start-up, 22/22 Amp DC Max. Input, 2 MPPTs, 10 kW AC Output, 11 kVA AC Max. Apparent, 50/60 Hz AC Operating, 15.9 Amp AC Output, 0.8 Leading - 0.8 Lagging Power Factor, <1.5% Harmonic Distortion, 98.7% Efficiency, 98.1% European Weighted Efficiency, >99.5% MPPT Efficiency, Transformerless, 4000 mtr Max. Altitude, 4 Pins RS485 Connector Communication Port, LCD, 2 x 20 Z Display, Intelligent Fan-Cooling Cooling, <60 dBA, MC4/Terminal Connectors Connection, IP65, -25 to 60 deg C, 0-100% Relative Humidity, 563 mm Height, 310 mm Width, 219 mm Depth, 18.9 kg, IEC 62109-1, IEC 62109-2, AS 3100, EN 61000-6-1, EN 61000-6-2

Key Specifications

chevron-down
SKU
SOLIS-3P10K-4G-AU
Brand
Solis
Product Type
Inverters

Technical Specifications

chevron-down
Looking for something specific? Search with keywords to help filter your required specifications.
search close

Additional Information

Features
  • Max. Efficiency 98.7%
  • Integrate with adjustable Volt-Watt & Volt-Var Function
  • Built-in DC-PV2 Switch comply with AS/NZS 5033 requirements
  • THDi <1.5% Low Harmonic Distortion against grid
  • DRM Integrated, fully comply with AS/NZS 4777.2:2020
  • 2 MPPT Design with Precise MPPT Algorithm
  • Integrated Export Power Management
  • Voltage Active Power & Reactive Power
  • Support 24h Consumption monitoring with a smart meter
Standard Pack Size 1
UNSPSC Class 26111600
UOM EA
Vendor Product SOLIS-3P10K-4G-AU
AC Operating Frequency 50/60 Hz
AC Nominal Voltage 3/N/PE 230V/400V
AC Max. Apparent Power 11 kVA
AC Output Current 15.9 Amp
AC Output Power 10 kW
Communication Port 4 Pins RS485 Connector
Connection Type MC4/Terminal Connectors
DC Input Power 15 kW
DC Input Voltage 1000 Volt
DC Max. Input Current 22 Amp
Cooling Method Intelligent Fan-Cooling
DC MPPT Voltage Range 160-850 Volt
DC Nominal Voltage 600 Volt
DC Start-up Voltage 180 Volt
Display Type LCD 2 x 20 Z
Depth 219 mm
European Weighted Efficiency 98.10%
IP Rating IP65
Height 563 mm
Efficiency 98.70%
Item Weight 18.9 kg
Max. Operating Altitude 4000 Mtr
Number of MPPTs 2
MPPT Efficiency >99.5%
Noise Level <60 dBA
Operating Temperature -25 to 60 deg C
Phase 3 Phase
Power Factor 0.8 Leading - 0.8 Lagging
Relative Humidity 0-100%
Total Harmonic Distortion <1.5%
Topology Transformerless
Width 310 mm
