Alco Heatshrink Tube Thin Wall 25-12.5mm 1.2m Black

Description

Heatshrink Tubing Thin Wall, Shrink Diameter From: 25 mm, Shrink Diameter To: 12.5 mm, > 50%/< 10% Radial/Longitudinal Shrink Ratio, Thin Wall Type, 0.8 mm Wall Thickness Recovered, 580% Elongation, 110 deg C Shrink Temperature, 15.5 Mpa Tensile Strength, ?15 kV/mm Dielectric Strength, UL 224 Flammability Rating, Ethylene Vinyl Acetate, Black, -55 to 125 deg C, 1.2 mtr Length

Key Specifications

Barcode (EAN-13)	9328587022989
SKU	ALCHSTNW25/12.5BK
Brand	Alco
Product Type	Heatshrink Tubing

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Heatshrink is ideally used for heavy duty and general purpose use i.e. electrical insulation, termination, splicing, bundling, cable protection and strain relief Low shrink temperature and flame retardant Flexible and UV resistant
Standard Pack Size	1
UNSPSC Class	39121700
UOM	EA
Vendor Product	HSTNW25/12.5BK
Colour	Black
Flammability Rating	UL 224
Elongation	580%
Dielectric Strength	?15 kV/mm
Material	Ethylene Vinyl Acetate
Shrink Diameter From	25 mm
Shrink Diameter To	12.5 mm
Tensile Strength	15.5 MPa
Temperature	-55 to 125 deg C
Shrink Ratio	> 50%/< 10% Radial/Longitudinal
Wall Type	Thin
Shrink Temperature	110 deg C
Wall Thickness Recovered	0.8 mm
