ASI Lamps Type 84 Sub-Miniature Lamp T1-1/4 28V 40mA Flange 0.15 MSCP 10000 hrs C2F Filament 4.6x13.6mm
Description
Indicator Lamp, Sub-Miniature, T1-1/4, 28 Volt, 40 mA, Flange Base, 0.15 MSCP, 10000 hrs Average Life, C2F Filament, 4.6 mm Overall Diameter, 13.6 mm Overall Length
Key Specifications
| SKU |
ASS84-028/40
|
|---|---|
| Brand |
ASI Lamps
|
| Range Name |
Type 84
|
| Product Type |
Indicator Lamps Sub-Mini
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 1 |
|---|---|
| UNSPSC Class | 39121500 |
| UOM | EA |
| Vendor Product | 084-028/040 |
| Average Lamp Life | 10000 hrs |
| Base Type | Flange |
| Diameter | 4.6 mm |
| Filament | C2F |
| Current | 40 mA |
| Lamp Shape | T1-1/4 |
| MSCP | 0.15 MSCP |
| Voltage | 28 Volt |
