Bambach 2.5mm 1 Core Black High Temperature Flexible Wire Silicone Rubber

chevron-left

Description

chevron-down
Flexible Wire, High Temperature, 2.5 mm, Class 5 Tinned Annealed Copper, 0.6-1 kV, 50 Amp, 1 Core, 50/0.25 mm Strands, 4 mm Overall Diameter, 24 mm Bend Radius, Silicone Rubber R-S-200 Insulation, Black Insulation, Unsheathed, -50 to 200 deg C, AS/NZS 1125 AS/NZS 3808 AS/NZS 3191 AS/NZS 5000.1 IEC 60228

Key Specifications

chevron-down
SKU
BAM18765ABK
Brand
Bambach
Range Name
Silicone Rubber 200

Technical Specifications

chevron-down
Looking for something specific? Search with keywords to help filter your required specifications.
search close

Additional Information

Features
  • R-S-200 insulation has a very wide operating range between -50 deg C and + 200 deg C
  • Oxygen free tinned copper for high conductivity soldered connections and corrosion protection
  • Silicone rubber exhibits excellent electrical resistance
  • Good flame retardance with zero halogens
  • Wide Temperature Range - Silicone rubber insulation is suitable in extreme high and low temperatures
  • Flexible Stranding - Class 5 flexible conductor stranding
  • Acid and Oil Resistance- Good resistance to oils, gasoline and some acids
  • Halogen Free- Silicone rubber insulation does not release corrosive gases when ignited
Standard Pack Size 100
UNSPSC Class 26121600
UOM MTR
Vendor Product 18765ABK
Bend Radius 24 mm
Conductor Type Class 5 Tinned Annealed Copper
Conductor Size 2.5 mm
Current 50 Amp
Insulation Material Silicone Rubber R-S-200
Insulation Colour Black
Overall Diameter 4 mm
Number of Cores 1 Core
Sheath Material Unsheathed
Standards AS/NZS 1125 AS/NZS 3808 AS/NZS 3191 AS/NZS 5000.1 IEC 60228
Stranding 50/0.25 mm
Temperature -50 to 200 deg C
Voltage 0.6-1 kV
