Belden 1864A U/UTP Data Cable Cat5 Multi-Conductor 25 Pair 24AWG Polyolefin/PVC Blue 305M
Description
U/UTP Data Cable Cat5 25 Pair, 300 Volt RMS, 24 AWG, 100 MHz Bandwidth, 9.38 Ohm/100 mtr at 20 deg C Conductor Resistance, Cat5 U/UTP-Unshielded Cable, 25 Pair, Bend Radius: 139.7mm, 444.820 N Max. Pulling Force, Solid Bare Copper Conductor, Rip Cord Filler, Polyolefin Insulation, PVC Sheath, Blue Sheath,-30 to 75 deg C, 305 mtr Length, 13.360mm Outside Diameter
Key Specifications
| SKU |
BEL1864A0061000
|
|---|---|
| Brand |
Belden
|
| Product Type |
Cat5 Cable
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 305 |
|---|---|
| UNSPSC Class | 43223300 |
| UOM | MTR |
| Vendor Product | 1864A 0061000 |
| Cable Type | Cat5 U/UTP-Unshielded |
| Bend Radius | 139.7mm |
| Conductor Resistance | 9.38 Ohm/100 mtr at 20 deg C |
| Conductor Size | 24 AWG |
| Conductor Material | Solid Bare Copper |
| Filler Material | Rip Cord |
| Frequency Bandwidth | 100 MHz |
| Insulation Material | Polyolefin |
| Max. Pulling Force | 444.820 N |
| Pair Count | 25 Pair |
| Outside Diameter | 13.360mm |
| Sheath Colour | Blue |
| Sheath Material | PVC |
| Temperature | -30 to 75 deg C |
| Voltage | 300 Volt |
