Belden UTP Data Cable Cat6 4 Pair 24AWG Gel Filled Polyolefin/Polyethylene Black 305M
Description
CAT 6 Data Cable UTP, 300 Volt, Solid, 24 AWG, 0.5 mm Conductor Diameter, 8.9 Ohms/100m Conductor Resistance, 550 MHz Frequency Bandwidth, Cat 6 UTP, 4 Pair, 70 mm Bend Radius, Bare copper Conductor, Gel Compound Water-Blocking Filler, Polyolefin Insulation, Polyethylene Sheath, Black Sheath, 40 to 60 deg C, 305 mtr Length, 6.8 mm Outside Diameter
Key Specifications
| Barcode (EAN-13) |
799936113587
|
|---|---|
| SKU |
BELBA250010A3
|
| Brand |
Belden
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 305 |
|---|---|
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | BA250 010A3 |
| Cable Type | Cat 6 UTP |
| Bend Radius | 70 mm |
| Conductor Diameter | 0.5 mm |
| Conductor Resistance | 8.9 Ohms/100m |
| Conductor Size | 24 AWG |
| Conductor Type | Solid |
| Conductor Material | Bare copper |
| Filler Material | Gel Compound Water-Blocking |
| Frequency Bandwidth | 550 MHz |
| Insulation Material | Polyolefin |
| Pair Count | 4 |
| Outside Diameter | 6.8 mm |
| Sheath Colour | Black |
| Sheath Material | Polyethylene |
| Temperature | 40 to 60 deg C |
| Voltage | 300 Volt |
