Brilliant Lighting Ceiling Sweep Fan 4 Blade 1220mm 3 Speed Wall Controller Painted Plywood White Hangsure
Description
Ceiling Sweep Fan, Fan Size: 1220mm, 240 Volt, Motor Wattage: 65/37/19 Watt, Motor Speed: 202/149/100 rpm, Control Type: 3 Speed Wall Controller, Air Flow Rate: 7699/5334/3349 cu-m/hr, 11 deg Blade Pitch, Motor Type: AC, Ceiling Rake: 32 deg (Without Receiver), Number of Blades: 4, Hangsure Mounting, Steel/Metal Body, Painted Plywood Blade, Steel/Metal Canopy, White Body, White Blade, 320mm Height
Key Specifications
| Barcode (EAN-13) |
9312641115007
|
|---|---|
| SKU |
BRI100010/05
|
| Brand |
Brilliant Lighting
|
| Range Name |
Tempo
|
| Product Type |
Ceiling Sweep Fans
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Features |
|
|---|---|
| Standard Pack Size | 1 |
| UNSPSC Class | 40101600 |
| UOM | EA |
| Vendor Product | 100010/05-NLA |
| Air Flow Rate | 7699/5334/3349 cu-m/hr |
| Blade Colour | White |
| Blade Pitch | 11 Degree |
| Body Colour | White |
| Blade Material | Painted Plywood |
| Body Material | Steel/Metal |
| Canopy Material | Steel/Metal |
| Ceiling Rake | 32 Degree (Without Receiver) |
| Fan Size | 1220 mm |
| Control Type | 3 Speed Wall |
| Motor Speed | 202/149/100 rpm |
| Height | 320mm |
| Motor Type | AC |
| Motor Wattage | 65/37/19 Watt |
| Mounting Method | HangSure |
| Number of Blades | 4 |
| Voltage | 240 Volt |
