Clipsal ResiMax Meter Box Victoria W470mm H430mm D280mm Surface Mount Iron Galvanised
Description
Meter Box Victoria, Service Facilities: C/W Fuse Holder & Meter Link, 430mm Height, 470mm Width, 280mm Depth, Ventilated Removable Door, Padlock Lock, IP23, Cable Entry: Knock-Out Top and Bottom, Knock-Out Rear, Surface, Iron, Galvanised
Key Specifications
| Barcode (EAN-13) |
9311554302115
|
|---|---|
| SKU |
CLI230MV
|
| Brand |
Clipsal
|
| Range Name |
Resi MAX
|
| Product Type |
Meter Boxes Domestic
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 1 |
|---|---|
| UNSPSC Class | 39121100 |
| UOM | EA |
| Vendor Product | 230MV |
| Cable Entry | Knock-Out Top and Bottom/Knock-Out Rear |
| Door Type | Ventilated Removable |
| Enclosure Depth | 280 mm |
| Enclosure Height | 430 mm |
| Enclosure Width | 470 mm |
| Finish | Galvanised |
| IP Rating | IP23 |
| Lock Type | Padlock |
| Material | Iron |
| Mounting Method | Surface |
| Service Facilities | C/W Fuse Holder & Meter Link |
