Clipsal 56 Series Switch Socket Outlet Surface Mounting Weatherproof 1Ph 20A 250V 3 Pin Round Chemical Grey IP66
Description
Switch Socket Outlet Surface Mounting Weatherproof, 1 Phase, 20 Amp, 250 Volt, 50 Hz, 3 Pole, 3 Pin Round, 1P + N + E, Screw, 2 x M20, 1 x M25, Terminal Capacity: 2.5 to 6 mm, Surface Mount, IP66, ABS Cover, Phosphor Bronze Pin, Chemical Resistant Grey, 204 mm Height, 101 mm Width, 108 mm Depth, -25 to 75 deg C
Key Specifications
| Barcode (EAN-13) |
9311554311537
|
|---|---|
| SKU |
CLI56C320CG
|
| Brand |
Clipsal
|
| Range Name |
56 Series
|
| Product Type |
Switch Sockets
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 1 |
|---|---|
| UNSPSC Class | 39122200 |
| UOM | EA |
| Vendor Product | 56C320-CG |
| Colour | Chemical Resistant Grey |
| Conduit Entry | 2 x M20/1 x M25 |
| Connection Type | Screw |
| Current | 20 Amp |
| Depth | 108 mm |
| Frequency | 50 Hz |
| Height | 204 mm |
| IP Rating | IP66 |
| Mounting Method | Surface |
| Number Of Poles | 3 Pole |
| Phase | 1 Phase |
| Pin Configuration | 3 Pin Round (1 + Neutral + Earth) |
| Temperature | -25 to 75 deg C |
| Terminal Capacity | 2.5-6 mm |
| Voltage | 250 Volt |
| Width | 101 mm |
