CMG Electric Motor Squirrel Cage Induction 4P 200kW 3Ph 415V 355LB Frame Foot Mount

Description

Electric Motor Squirrel Cage Induction, 415 Volt AC, 200 kW, 50 Hz, 3 Phase, Number of Speeds: Single, 4 Pole, IP66, Frame: 355LB, Shaft Size: 85-110 mm, Clockwise Rotation, Counter-Clockwise, Duty Cycle: S1, Roller Bearing, Foot Mount, Insulation Class: Class H, -20 to 120 deg C, Totally Enclosed Fan Cooled Cast Iron, Bright Red Orange, 145 mm Diameter x 1630-1670 mm Length x 845 mm Height

Key Specifications

SKU	CMGM3420000B3PPA
Brand	CMG
Range Name	PPA Series
Product Type	Motors SCIM

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	PPA range of motors are premium, high efficiency motors designed to withstand even the most arduous of environments The PPA meets world market needs and standards Thru flush grease relief valves 20 year design life Low noise low vibration design Ex e, Ex nA and Ex t hazardous locations For arduous environments, mining industry, food and beverage industry, chemical processing and petrochemical applications
Standard Pack Size	1
UNSPSC Class	26101100
UOM	EA
Vendor Product	M3420000B3PPA
Colour	Bright Red/Orange
Diameter	145 mm
Bearing Type	Roller
Frame	Size 355LB
Height	845 mm
Frequency	50 Hz
Insulation Class	Class H
IP Rating	IP66
Horsepower	200 kW
Mounting Method	Foot
Material	Totally Enclosed Fan Cooled Cast Iron
Number of Speeds	Single
Number Of Poles	4 Pole
Phase	3 Phase
Rotation	Clockwise, Counter-Clockwise
Shaft Size	85-110 mm
Temperature	-20 to 120 deg C
Voltage	415 Volt AC
