CMP Products Cable Gland Locknut Hex M20 x 1.5 Nickel Plated Brass

Description

Cable Gland Counter Nut Hexagonal, M20 x 1.5 mm, 1.5 mm, 24 mm Width Across Flats, 27.7 mm Width Across Corners, Brass Body, Nickel Plated, 3.2 mm Depth

Key Specifications

SKU	CMP20LN5
Brand	CMP Products
Product Type	Gland Accessories

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Securing brass cable glands and accessories to a gland plate or into equipment Brass cable gland locknuts: Recommended in securing brass Cable Glands and Accessories to a gland plate or into equipment. In metric thread form CMP offers brass locknuts in a choice of standard duty and heavy duty options for sizes up to and including M32. The part numbers are distinguished by an additional letter H, e.g. 20LN = standard duty, and 20HLN = heavy duty. From size M40 all brass metric locknuts are considered to be heavy duty Zinc Plated Mild Steel cable gland locknuts: A cost effective alternative to brass locknuts and should be used only in dry, low humidity conditions Aluminium cable gland locknuts: Recommended when installing aluminium Cable Glands to prevent the galvanic corrosion which can occur when dissimilar metals are coupled together Stainless Steel cable gland locknuts: Corrosion resistant with increased strength at high temperatures
Standard Pack Size	1
UNSPSC Class	39121400
UOM	EA
Vendor Product	20LN5
Depth	3.2 mm
Body Material	Brass
Finish	Nickel Plated
Thread Pitch	1.5 mm
Thread Size	M20 x 1.5 mm
Width Across Corners	27.7 mm
Width Across Flats	24 mm
