CMP Products Cable Gland Unarmoured Barrier 6.1-11.7mm M20 IP68

$CMP_Products\CMP_PXSS2KREX_Explosive_Atmosphere.jpg$

Description

Cable Gland, Unarmoured, Barrier, M20, 15 mm Thread Length, 6.1 mm Min. Sheath OD, 11.7 mm Max. Sheath OD, 11.7 mm Max. Bedding OD, 30 mm Width Across Flats, 33 mm Width Across Corners, For: All Types of Unarmoured and Braid Cable, Exd, Exe, Ex nR, Ex ta, Number of Conductors: 11, 53.1 mm Protrusion Length, IP68, Thermoset Elastomer Seal, Brass Body, Nickel Plated Finish, 68.1 mm Overall Length, -60 to 85 deg C

Key Specifications

SKU	CMP20SPXSS2KREX1RA5
Brand	CMP Products
Range Name	Type PXSS2K-REX
Product Type	Cable Glands Hazardous Area

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	RapidEx liquid pour sealing system Enhances reliability, reduces risk Reduces man hours Reduces cost Direct and remote installation Superior levels of cable retention Displacement type environmental seal Designed to prevent Cold flow Deluge protected
Standard Pack Size	1
UNSPSC Class	39121400
UOM	EA
Vendor Product	20SPXSS2KREX1RA5
Body Material	Brass
Finish	Nickel Plated
For Use With	Unarmoured & Braid Cable
Hazardous Area Rating	Exd Exe Ex nR Ex ta
IP Rating	IP68
Min. Sheath OD	6.1 mm
Max. Bedding OD	11.7 mm
Max. Sheath OD	11.7 mm
Number of Conductors	11
Overall Length	68.1 mm
Protrusion Length	53.1 mm
Seal Material	Thermoset Elastomer
Thread Length	15 mm
Temperature	-60 to 85 deg C
Thread Size	M20
Width Across Corners	33 mm
Width Across Flats	30 mm
