CMP Products Metal Cable Gland Armoured General Purpose 23.7-33.9mm M32 IP68

Description

Cable Gland Metal Armoured General Purpose, M32, 20 mm Thread Length, 23.7 mm Min. Sheath OD, 33.9 mm Max. Sheath OD, 26.3 mm Max. Bedding OD, 1.6 mm Min. Armour Wire, 2 mm Max. Armour Wire, 46 mm Width Across Flats, 51 mm Width Across Corners, 55 mm Protrusion Length, IP68, Brass Body, Thermoplastic Elastomer Seal, Nickel Plated, -60 to 150 deg C

Key Specifications

SKU	CMP32CWD1RA5/A
Brand	CMP Products

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	High quality durable material Robust, heavy duty design Metal-to-metal armour clamping Direct and remote installation Controlled outer 'load retention' seal Unique OSTG prevents overtightening Deluge proof EMC tested
Standard Pack Size	1
UNSPSC Class	39121400
UOM	EA
Vendor Product	32CWD1RA5/A
Body Material	Brass
Finish	Nickel Plated
IP Rating	IP68
Max. Armour Wire	2 mm
Max. Bedding OD	26.3 mm
Max. Sheath OD	33.9 mm
Min. Armour Wire	1.6 mm
Min. Sheath OD	23.7 mm
Protrusion Length	55 mm
Temperature	-60 to 150 deg C
Seal Material	Thermoplastic Elastomer
Thread Length	20 mm
Thread Size	M32
Width Across Corners	51 mm
Width Across Flats	46 mm
