CMP Products Hazardous Area Threaded Stopper Plug Hex Head M16 Nickel Plated Brass Exd/Exe

Description

Hazardous Area Stopper Plug Threaded Hex, M16 Cable Gland Size, Exd, Exe, 22 mm Width Across Flats, 24.2 mm Width Across Corners, Brass Body, Nickel Plated, -60 to 200 deg C, 5 mm Protrusion Length

Key Specifications

SKU	CMP757DM15
Brand	CMP Products
Product Type	Hazardous Area Accessories

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Provides means of blanking unused cable entries Temporary or permanent Component approved stopper plugs designed to close unused cable entry holes in explosion protected equipment For industrial or safe area use -60 deg C to 200 deg C (metallic versions) Globally marked, IECEx, ATEX, cCSAus and UL
Standard Pack Size	1
UNSPSC Class	39121400
UOM	EA
Vendor Product	757DM15
Hazardous Area Rating	Exd, Exe
Cable Gland Size	M16
Finish	Nickel Plated
Body Material	Brass
Protrusion Length	5 mm
Temperature	-60 to 200 deg C
Width Across Corners	24.2 mm
Width Across Flats	22 mm
