Crouse Hinds Hazardous Area Cable Gland Armoured Barrier 10.2-15.8mm M20 IP66/67
Description
Hazardous Area Cable Gland Armoured Barrier Type, M20, 14 mm Thread Length, 10.2 mm Min. Sheath OD, 15.8 mm Max. Sheath OD, 8 mm Max. Bedding OD, 0.9 mm Min. Armour Wire, 1.25 mm Max. Armour Wire, Exd, Exe, Ex tD, 27 mm Width Across Flats, 31 mm Width Across Corners, IP66/67, Brass Body, Nickel Plated, 15.8 mm Overall Length
Key Specifications
| Barcode (EAN-13) |
9323952097159
|
|---|---|
| SKU |
CRUTWAB1M16
|
| Brand |
Crouse Hinds
|
| Range Name |
Terminator TWAB
|
| Product Type |
Cable Glands Hazardous Area
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Features |
|
|---|---|
| Standard Pack Size | 10 |
| UNSPSC Class | 39121400 |
| UOM | EA |
| Vendor Product | TWAB1M16 |
| Body Material | Brass |
| Finish | Nickel Plated |
| Hazardous Area Rating | Exd, Exe, Ex tD |
| IP Rating | IP66/67 |
| Max. Armour Wire | 1.25 mm |
| Max. Bedding OD | 8 mm |
| Max. Sheath OD | 15.8 mm |
| Min. Armour Wire | 0.9 mm |
| Min. Sheath OD | 10.2 mm |
| Overall Length | 15.8 mm |
| Thread Length | 14 mm |
| Thread Size | M20 |
| Width Across Corners | 31 mm |
| Width Across Flats | 27 mm |
