Flexicon Flexible Conduit Corrugated Heavy Weight 16mm 50M Nylon PA12 Orange

$Flexicon\Flexicon_FPAH_Black.jpg$

Description

Flexible Conduit, Corrugated, Heavy Weight, 16 mm, 11.5 mm ID, 15.8 mm OD, 50 mtr, 45 mm Bend Radius, Fine, Nylon PA12, Orange Sheath, -40 to 120 deg C

Key Specifications

SKU	FLXFPAH16OR-50M
Brand	Flexicon
Range Name	FPAH System
Product Type	Flex Conduit Heavy Duty

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Construction heavy weight, flame retardant, nylon (PA6) corrugated flexible conduit Typical applications all types of machinery and public buildings where high mechanical strength required High mechanical strength High impact resistance UL 94 V2 flame retardancy Halogen, sulphur and phosphorus free UV resistant Abrasion resistant Highly resistant to solvents and oils
Standard Pack Size	50
UNSPSC Class	39131700
UOM	MTR
Vendor Product	FPAH16OR-50M
Inside Diameter	11.5 mm
Conduit Size	16 mm
Bend Radius	45 mm
Outside Diameter	15.8 mm
Sheath Colour	Orange
Temperature	-40 to 120 deg C
