Garland Figure 8 Speaker Cable 4.34mm 138/0.2mm PVC/PVC Black

Description

Figure 8 Speaker Cable, 4.34 mm, Bare Copper, 3mm Conductor Diameter, Bend Radius: Install: 45mm, 2 Core, Elongation: Insulation: >100%, Pulling Tension: 606 N, Stranding: 138/0.2mm, Insulation Thickness: 0.7mm, Conductor Resistance: DC: 5.43 Ohm/km at 20 deg C, Insulation Resistance: 50 MOhm.km at 20 deg C, PVC Insulation, PVC Sheath, Black Insulation, Black Sheath,-15 to 70 deg C

Key Specifications

Barcode (EAN-13)	9329849003401
SKU	GARTCW138BK500
Brand	Garland
Product Type	Speaker Cable

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	500
UNSPSC Class	26121600
UOM	MTR
Vendor Product	TCW138BK500
Bend Radius	Install: 45mm
Conductor Resistance	DC: 5.43 Ohm/km at 20 deg C
Conductor Diameter	3mm
Conductor Size	4.34 mm
Conductor Type	Bare Copper
Elongation	Insulation: >100%
Insulation Material	PVC
Insulation Colour	Black
Insulation Thickness	0.7mm
Insulation Resistance	50 MOhm.km at 20 deg C
Number of Cores	2 Core
Pulling Tension	606 N
Sheath Colour	Black
Sheath Material	PVC
Stranding	138/0.2mm
Temperature	-15 to 70 deg C
