Std Pack Size
305
OUR P/N:
GARUTPL5EMTPYE305W
UTP Data Cable Cat5e 4 Pair, 24 AWG/0.23 mm, 0.609mm Conductor Diameter, Stranding: 7/0.203mm, 93.8 Ohm/km at 20 deg C Conductor Resistance, 1000 MOhm.km at 20 deg C Insulation Resistance, 0.18mm Insulation Thickness, Cat5e UTP Cable, Elongation: Insulation: >300%, Outer Sheath: >100%, 4 Pair, Bend Radius: Install: 55mm, 126 N Max. Pulling Force, Tensile Strength: Before Aging: >13.8MPa, Bare Copper Conductor, Rip Cord Filler, PE Insulation, Yellow Sheath,-15 to 70 deg C, 305 mtr Length
Additional Information
| Brand | Garland |
|---|---|
| Standard Pack Size | 305 |
| UNSPSC Class | 43223300 |
| UOM | MTR |
| Vendor Product | UTPL5EMTPYE305W |
| Elongation | Insulation: >300%/Outer Sheath: >100% |
| Product Type | Cat5E Cable |
| Max. Pulling Force | 126 N |
| Tensile Strength | Before Aging: >13.8MPa |
| Filler Material | Rip Cord |
| Pair Count | 4 Pair |
| Stranding | 7/0.203mm |
| Cable Type | Cat5e UTP |
| Insulation Material | PE Compound |
| Length | 305 mtr |
| Sheath Colour | Yellow |
| Bend Radius | Install: 55mm |
| Insulation Resistance | 1000 MOhm.km at 20 deg C |
| Insulation Thickness | 0.18mm |
| Conductor Diameter | 0.609mm |
| Conductor Size | 24 AWG/0.23 mm |
| Conductor Resistance | 93.8 Ohm/km at 20 deg C |
| Conductor Material | Bare Copper |
| Temperature | -15 to 70 deg C |
