Hager Combination RCD Circuit Breaker RCBO 1Pole 32 Amp 240V AC 6 kA 1Module 17.5mm DIN Rail
Description
Combination RCD Circuit Breaker RCBO Type A, 32 Amp, 240 Volt AC, 50 Hz, Interrupt Capacity: 6 kA, Trip Sensitivity: 30 mA, Number of Poles: 1, Number of Modules: 1, 17.5mm Module Width, Trip Characteristic: C Curve, 1/10 mm Flexible, 1/16 mm Rigid Terminal Connection, Screw, IP20, DIN Rail,-25 to 80 deg C, 92mm Height, 17.7mm Width, 70mm Depth
Key Specifications
| Barcode (EAN-13) |
3250611069560
|
|---|---|
| SKU |
HAGADC332T
|
| Brand |
Hager
|
| Range Name |
onekombo
|
| Product Type |
Combination RCBO
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 1 |
|---|---|
| UNSPSC Class | 39121600 |
| UOM | EA |
| Vendor Product | ADC332T-NLA |
| Current | 32 Amp |
| Connection Type | Screw |
| Height | 92mm |
| Depth | 70mm |
| Modules | 1 Module 17.5mm |
| Frequency | 50 Hz |
| Interrupt Capacity | 6 kA |
| Mounting Method | DIN Rail |
| IP Rating | IP20 |
| Number Of Poles | 1 Pole |
| Temperature | -25 to 80 deg C |
| Trip Characteristic | C Curve |
| Terminal Connection | 1/10 sq-mm Flexible/ 1/16 sq-mm Rigid |
| Trip Sensitivity | 30 mA |
| Voltage | 240 Volt |
| Width | 17.7mm |
