Hager 144 Pole Switchboard Enclosure Flush Mount 160 Amp Plastic/Metal

chevron-left

Description

chevron-down
Switchboard Enclosure, 160 Amp, 6 Rows, 144 Modules, IP30, Flush, Plastic/Metal, White, Powder Coated, 1137mm Height x 600mm Width x 150mm Depth

Key Specifications

chevron-down
Barcode (EAN-13)
3250612710751
SKU
HAGFU62DN
Brand
Hager
Product Type
Switchboard Kits & Enclosures

Technical Specifications

chevron-down
Looking for something specific? Search with keywords to help filter your required specifications.
search close

Additional Information

Features
  • The Vega D enclosure range has been designed to complement a vast array of installations
  • The range is available in either surface or flush mount configurations and in modular rows of either 24I or 18I modules
  • The enclosures are configured from 4-7 rows of 24 modules (96 mod-168 mod)
  • They combine sheet metal and injected plastic so as to achieve a light yet strong enclosure guaranteeing class II isolation
Standard Pack Size 1
UNSPSC Class 39121100
UOM EA
Vendor Product FU62DN
Colour White
Dimensions 1137 mm Height x 600 mm Width x 150 mm Depth
Current 160 Amp
IP Rating IP30
Modules 144 Module
Material Plastic/Metal
Number of Rows 6 Rows
Mounting Method Flush
