Hager Miniature Circuit Breaker D Curve 40Amp 6kA 1Pole 1Module DIN Rail Mount
Description
Miniature Circuit Breaker D Curve, 240/415 Volt AC, 40 Amp, Interrupt Capacity: 6 kA, Number of Modules: 1, Number of Poles: 1, Trip Characteristic: D Curve, 2.8 N/m Tightening Torque, Screw Terminal, IP20, 4000 Cycles, 1 to 25 mm Flexible/1 to 35 mm Rigid Cable, DIN Rail, 30 deg C, 84.6mm Height x 17.7mm Width x 70mm Depth
Key Specifications
| Barcode (EAN-13) |
3250614353031
|
|---|---|
| SKU |
HAGMDN140P
|
| Brand |
Hager
|
| Product Type |
Mini Circuit Breakers
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 1 |
|---|---|
| UNSPSC Class | 39121600 |
| UOM | EA |
| Vendor Product | MDN140P |
| Cable Size | 1-25 sq-mm Flexible / 1-35 sq-mm Rigid |
| Current | 40 Amp |
| Depth | 70 mm |
| Height | 84.6 mm |
| Interrupt Capacity | 6 kA |
| IP Rating | IP20 |
| Mounting Method | DIN Rail |
| Number Of Poles | 1 Pole |
| Temperature | 30 deg C |
| Terminal Type | Screw |
| Tightening Torque | 2.8 Nm |
| Voltage | 240-415 Volt |
| Width | 17.7 mm |
