Heinelec Miniature Circuit Breaker 2 Pole 40 Amp 6 kA 2 Module 51.6mm Clip Tray Surface Mount

chevron-left

Description

chevron-down
Miniature Circuit Breaker, 240 Volt AC, 40 Amp, 50/60 Hz, Interrupt Capacity: 6 kA, Number of Modules: 2, 51.6mm Module Width, Number of Poles: 2, Tunnel Terminal, IP2X, Clip Tray, Surface,-40 to 85 deg C, 149mm Height x 51.6mm Width x 71.8mm Depth

Key Specifications

chevron-down
SKU
HEISFM2-G3-40-2
Brand
Heinelec
Range Name
SFM Series
Product Type
Mini Circuit Breakers

Technical Specifications

chevron-down
Looking for something specific? Search with keywords to help filter your required specifications.
search close

Additional Information

Features
  • AC circuit breaker
  • Hydrauilic magnetic technology
  • 100% rating capacity independent of ambient temperture
  • IP2X finger proof line and load box (tunnel) type terminals can accommodate copper cables up to 50 sq-mm
  • Available in various currents and time delays
  • Precision tripping characterstics
  • Reset immediately after over load
Standard Pack Size 1
UNSPSC Class 39121600
UOM EA
Vendor Product SFM2-G3-40-2
Depth 71.8 mm
Current 40 Amp
Frequency 50/60 Hz
Height 149 mm
Interrupt Capacity 6 kA
IP Rating IP2X
Mounting Method Clip Tray/Surface
Number Of Poles 2 Pole
Terminal Type Tunnel
Temperature -40 to 85 deg C
Voltage 240 Volt
Width 51.6 mm
