IME AC Ammeter Analogue Moving Iron Direct Connection 0-5A x 5 90Deg 96mm W Panel Mount

Description

AC Ammeter Analogue Moving Iron, 0 to 5 Amp With x 5 Over-Scale, 600 Volt AC, 0-5/25 Amp, 50/45-65 Hz, Direct Connection, 90 deg Deflection Accuracy Class 1.5, -25 to 50 deg C, Analogue Display, 96 mm Height x 96 mm Width, Panel Mount, Polycarbonate, 92 mm Height x 92 mm Width x 69 mm Depth

Key Specifications

Barcode (EAN-13)	9321807025319
SKU	IMERQ96EAAC5A
Brand	IME
Range Name	RQ96
Product Type	Ammeters

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Accuracy class 1.5 IP52 rated front frame
Standard Pack Size	1
UNSPSC Class	41113600
UOM	EA
Vendor Product	RQ96EAAC5A
Current	0-5/25 Amp
Depth	69 mm
Display	Analogue
Frame Size	96mm x 96mm
Frequency	50/45-65 Hz
Height	92 mm
Mounting Method	Panel
Operation Form	Direct Connection
Readout Form	90 deg Deflection Accuracy Class 1.5
Scale	0 to 5 Amp with x5 Over-Scale
Voltage	600 Volt
Temperature	-25 to 50 deg C
Width	92 mm
