IPD Extension Socket Industrial 3Ph 40A 4 Pin Round Orange IP66
Description
Extension Socket Industrial, Angle: Straight, 3 Phase, 40 Amp, 500 Volt AC, 4 Pin Round, Orange, IP66, Screw, 16 mm, 37mm Cable Gland, 7-16mm Cable Diameter, Polycarbonate, 190 mm Depth
Key Specifications
| SKU |
IPDW66ES440
|
|---|---|
| Brand |
IPD
|
| Product Type |
Extension Sockets
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 36 |
|---|---|
| UNSPSC Class | 39121400 |
| UOM | EA |
| Vendor Product | W66ES440 |
| Angle | Straight |
| Cable Entry | 16 sq-mm |
| Cable Gland Size | 37 mm |
| Cable Nominal Diameter | 7-16 mm |
| Colour | Orange |
| Connection Type | Screw |
| Current | 40 Amp |
| Depth | 190 mm |
| IP Rating | IP66 |
| Pin Configuration | 4 Pin Round |
| Phase | 3 Phase |
| Voltage | 500 Volt |
