Legrand Combination RCD Circuit Breaker RCBO 4Pole 10 Amp 230/400V 10 kA 4Module 72mm DIN 35 Rail

Description

Combination RCD Circuit Breaker RCBO, 10 Amp, 230/400 Volt, 50 Hz, Interrupt Capacity: 10 kA, Trip Sensitivity: 30 mA, Number of Poles: 4, Number of Modules: 4, 72mm Module Width, Trip Characteristic: C Curve, 2 x 0.75 to 16 mm Flex/Rigid, 1 x 0.75 to 35 Rigid Terminal Connection, Cage, Captive Screw, IP20, IP40, DIN 35mm Rail, Polyamide and P.B.T Housing,-25 to 60 deg C, 83mm Height, 71.2mm Width, 78.05mm Depth

Key Specifications

Barcode (EAN-13)	3245064112338
SKU	LEG411233
Brand	Legrand
Product Type	Combination RCBO

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	411233
Current	10 Amp
Connection Type	Cage/ Captive Screw
Height	83 mm
Depth	78.05 mm
Modules	4 Module 72 mm
Frequency	50 Hz
Interrupt Capacity	10 kA
Mounting Method	DIN Rail
IP Rating	IP20/40
Number Of Poles	4 Pole
Temperature	-25 to 60 deg C
Trip Characteristic	C Curve
Terminal Connection	2 x 0.75-16 sq-mm Flex/Rigid / 1 x 0.75-35 Rigid
Trip Sensitivity	30 mA
Voltage	230-400 Volt
Width	71.2 mm
