Name: Contactor GP AC Operated 3P 10kW 12A AC3 28A AC1 240V 1NC
SKU: LOVBF1201A240
Availability: InStock

Skip to the beginning of the images gallery

Std Pack Size

OUR P/N:

LOVBF1201A240

You need to be registered and logged in to view product details and pricing

Description

Contactor General Purpose AC Operated, 240 Volt AC, AC3 Rating (kW): 10 at 55 deg C, AC3 Rating (Amps): 12, AC1 Rating (Amps): 28, 690 Volt, 1NC Auxiliary, 3 Pole, Screw Terminal, DIN Rail/Base Mount, IP20, -50 to 70 deg C, 126 mm Height, 45 mm Width, 80.7 mm Depth

Specifications

Additional Information

Additional Information
Brand	Lovato
Range Name	Orange BF
Standard Pack Size	1
UNSPSC Class	39121500
UOM	EA
Vendor Product	LOVBF1201A240
AC1 Rating (Amps)	28 Amp AC1
AC3 Rating (Amps)	12 Amp AC3
AC3 Rating (kW)	10 kW
Contact Configuration	1 Normally Closed Aux
Contact Voltage	690 Volt
Height	126 mm
IP Rating	IP20
Depth	80.7 mm
Number Of Poles	3 Pole
Mounting Method	DIN Rail/Base
Operating Coil Voltage	240 Volt AC
Temperature	-50 to 70 deg C
Product Type	Contactors General
Width	45 mm
Terminal Connection	Screw

Delivery and Returns

It is a long established fact that a reader will be distracted by the readable content of a page when looking at its layout.

Description

Technical Information TECHNICAL INFO

Specifications SPECS

Three-pole contactors, 9 to 110A in AC3 duty
Four-pole contactors, 25 to 125 A in AC1 duty
Power factor correction contactors, 7.5 to 60 kv at 400 volt
Versions with 2NO+2NC or 4NC main power poles
Highly conductive auxiliary contacts
AC or DC auxiliary supply
Low-consumption versions for control relays and 9-38 A contactors in AC3 duty

Contactor GP AC Operated 3P 10kW 12A AC3 28A AC1 240V 1NC

Lovato Contactor General Purpose AC Operated 3 Pole 10kW 12A AC3 28A AC1 240V 1NC Auxilary DIN Rail/Base Mount
