M-Elec Electric Vehicle Charger 22kW 400V 3Ph Type 2 IP64 32A 50/60Hz Bluetooth/WIFI OCPP 1.6J IK10 -30 to 50deg C 345mm

chevron-left
loader
Loading...

Description

chevron-down
Offering a remarkable 22 kW of charging capacity, this three phase EV charger is compatible with all EV car models. This charger ensures safety while catering specifically to the Australian market. Boasting a high-quality construction with a generous three-year warranty, it offers effortless installation by a licensed electrician. With an IP65 rating and IK10 durability, it features a Type 2 plug and comes complete with a 5m cable for added versatility. Additional back plates and cover accessories, allow you to prepare for additional EV charger installations, without having to install the actual units reducing the costs of set up for future proofing or fleet preparation. OCPP 1.6J protocol is already built in ready to integrate with your management software or app over WiFi or LAN. RFID and MODBUS available on request.

Key Specifications

chevron-down
SKU
MELSV-EVX2-22LW-3P5M
Brand
M-Elec
Range Name
EVC
Product Type
EV Charger

Technical Specifications

chevron-down
Looking for something specific? Search with keywords to help filter your required specifications.
search close

Additional Information

Features
  • Safe and efficient
  • Easy to Install
Standard Pack Size 1
UNSPSC Class 25175000
UOM EA
Vendor Product SV-EVX2-22LW-3P-5M
IP Rating IP64
Power Output 22 kW
Height 345 mm
Width 191 mm
Input Frequency 50/60 Hz
Depth 149 mm
Phase 3 Phase
Input Voltage 400 Volt AC
Standards IEC 62196-2
Connector Type Type 2
Operating Temperature -30 to 50 deg C
Certifications R cm / ISO 14443A / ISO 14443B
Communication Protocol OCPP 1.6J
IK Rating IK10
Item Weight 5.8 kg
Output Current 32 Amp
Wireless Technology Bluetooth / Wi-Fi
