NHP Din-Safe DIN-T Series RCBO 3P+N 10kA 63A C Curve 300mA Type A RCD Pigtail 54mm

chevron-left

Description

chevron-down
RCBO, 63 Amp, 400/415 Volt AC, 50/60 Hz, 10 kA Interrupt Capacity, 300 mA Trip Sensitivity, 3 Pole + N, C Curve, Inside: IP40, Outside: IP20, DIN-35 Rail Mounting,-5 to 40 deg C, 117.5mm Height, 53.4mm Width, 71.6mm Depth

Key Specifications

chevron-down
SKU
NHPDSRCBT63300A
Brand
NHP
Range Name
Din-Safe
Product Type
Combination RCBO

Technical Specifications

chevron-down
Looking for something specific? Search with keywords to help filter your required specifications.
search close

Additional Information

Standard Pack Size 1
UNSPSC Class 39121600
UOM EA
Vendor Product DSRCBT63300A
Current 63 Amp
Depth 71.6 mm
Height 117.5 mm
Frequency 50/60 Hz
IP Rating IP40 Inside/IP20 Outside
Interrupt Capacity 10 kA
Mounting Method DIN Rail
Number Of Poles 3 Pole
Temperature -5 to 40 deg C
Trip Characteristic C Curve
Voltage 400-415 Volt
Trip Sensitivity 300 mA
Width 53.4 mm
