NHP Miniature Circuit Breaker C Curve 63Amp 6 kA 3Pole 3Module 54mm DIN 35mm Rail
Description
Key Specifications
Barcode (EAN-13) |
5413656910602
|
---|---|
SKU |
NHPMOD6363
|
Brand |
NHP
|
Range Name |
MOD6
|
Product Type |
Mini Circuit Breakers
|
Technical Specifications
Additional Information
Features |
|
---|---|
Standard Pack Size | 1 |
UNSPSC Class | 39121600 |
UOM | EA |
Vendor Product | MOD6363 |
Depth | 76 mm |
Current | 63 Amp |
Electrical Life | 10000 Cycles |
Frequency | 50/60 Hz |
Height | 86 mm |
Interrupt Capacity | 6 kA |
IP Rating | IP20/40 |
Modules | 3 Module 54 mm |
Mounting Method | DIN Rail |
Number Of Poles | 3 Pole |
Phase | 2 Phase |
Temperature | 25 to 55 deg C |
Tightening Torque | 4.5 Nm |
Voltage | 415 Volt |
Width | 54 mm |
