Panduit Locking Forked Spade Insulated Single Grip 0.5-1mm M3.5 Stud Red 22.9mm OAL

chevron-left

Description

chevron-down
Locking Forked Spade Terminal, Insulated, Single Grip, Conductor Size: 0.5-1 mm, Stud Size: M3.5, Terminal Type: Spring, Snap, 600 Volt Maximum, Wire Strip Length: 7.9mm, Barrel Type: Bevelled, Serrated, Seam Type: Butted, Crimping Die: CT-100A, CT-600A (CT-500CH), CT-600A (CT-550CH), CT-1550, CT-1551, Mounting Method: Free Hanging, Body Material: Copper, Conductive Material: Copper, Insulation Material: Vinyl, Red Insulation, Tin Plated Finish, 221 deg F, 22.9mm Overall Length, 11.4mm Lug Length, 6.9mm Lug Width, 0.8mm Lug Thickness, 3.6mm Lug Inside Width, Barrel Length: 11.4mm, Max. Insulation Diameter: 3.8mm, 50 Pack

Key Specifications

chevron-down
SKU
PANEV18-6LFB-L
Brand
Panduit
Range Name
StrongHold
Product Type
Forked & Ring Terminals

Technical Specifications

chevron-down
Looking for something specific? Search with keywords to help filter your required specifications.
search close

Additional Information

Standard Pack Size 50
UNSPSC Class 39121400
UOM EA
Vendor Product EV18-6LFB-L
Barrel Length 11.4 mm
Barrel Type Bevelled/Serrated
Conductive Material Copper
Body Material Copper
Conductor Size 0.5-1mm
Crimping Die CT-100A/CT-600A (CT-500CH)/CT-600A (CT-550CH)/CT-1550/CT-1551
Finish Tin Plated
Insulation Diameter 3.8 mm
Insulation Colour Red
Insulation Material Vinyl
Lug Inside Width 3.6 mm
Lug Length 11.4 mm
Lug Thickness 0.8 mm
Lug Width 6.9 mm
Pack Size 50 Pack
Mounting Method Free Hanging
Overall Length 22.9 mm
Seam Type Butted
Stud Size M3.5 Stud
Temperature 221 deg F
Terminal Type Spring/Snap
Voltage Rating 600 Volt
Wire Strip Length 7.9 mm
