Sprecher+Schuh Cam Switch Changeover Without Off Position 1P 12A AC21 Panel Mount

$Sprecher\Sprecher_L2.jpg$

Description

Cam Switch Changeover Without Off Position, AC21 Rating: 12 Amp at 690 Volt AC, 690 Volt AC, 50/60 Hz, 1 Pole, 60 deg, Changeover Without Off Position, 2 Positions, Legend: I II, Rotary Actuator, 18-12 AWG, Screw Terminal, Tightening Torque: 1 Nm, Mechanical Durability: 1200 Cycles/hr, Panel Mount, IP20, IP65, -25 to 60 deg C, 48 mm Height, 48 mm Width, 72 mm Depth

Key Specifications

Barcode (EAN-13)	9321807138446
SKU	S&SCA-LE2-12-2501
Brand	Sprecher+Schuh
Range Name	L2
Product Type	Cam Switches Changeover

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Switch bodies with Touch-Proof terminals (IP 20) Long operational life and high reliability Positive switching action with clearly defined switching point All switch bodies are manufactured from self-extinguishing materials (corresponding to class UL 94 V0) Captive terminal screws already open for fast installation Robust screwdriver guide for easy wiring using manual or power screwdriver Clear terminal markings prevent wiring mistakes Easy access to switch terminals (angled screws) Switch handle assemblies available with either screw fixing or central nut mounting
Standard Pack Size	1
UNSPSC Class	39122200
UOM	EA
Vendor Product	CALE2122501
AC21 Rating	12 Amp AC21 @ 690 Volt
Actuator	Rotary
Conductor Size	18-12 AWG
Connection Type	Screw
Frequency	50/60 Hz
Depth	72 mm
Height	48 mm
IP Rating	IP20/65
Mechanical Durability	1200 Cycles/hr
Legend	I II
Mounting Method	Panel
Number of Positions	2 Posn
Number Of Poles	1 Pole
Switching Angle	60 deg
Temperature	-25 to 60 deg C
Switching Function	Changeover Without Off Position
Width	48 mm
Tightening Torque	1 Nm
