Contactor DC Operated 1NO Aux 110-125VDC 5.5kW 12A AC3 32A
Description
General Purpose DC Operated Contactor, 1 Normally Opened Aux, 110-125 Volt DC, 5.5 kW, 12 Amp AC3, 32 Amp AC1, 3 Pole, DIN Rail/Base Mount
Key Specifications
| Barcode (EAN-13) |
9321807224767
|
|---|---|
| SKU |
S&SCA7-12E-10/110E
|
| Brand |
Sprecher+Schuh
|
| Range Name |
CA7
|
| Product Type |
Contactors General
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 1 |
|---|---|
| UNSPSC Class | 39121500 |
| UOM | EA |
| Vendor Product | CA712E10110E |
| AC1 Rating (Amps) | 32 Amp AC1 |
| AC3 Rating (Amps) | 12 Amp AC3 |
| AC3 Rating (kW) | 5.5 kW |
| Contact Configuration | 1 Normally Opened Aux |
| Mounting Method | DIN Rail/Base |
| Number Of Poles | 3 Pole |
| Operating Coil Voltage | 110-125 Volt DC |
