Sprecher+Schuh Non-Reversing Contactor 3 Pole 90kW 190A AC3 275A AC1 100-250VAC/DC 1NO-1NC Auxiliary Electronic

chevron-left

Description

chevron-down
Non-Reversing Contactor, 100-250 Volt AC/DC, AC3 Rating (kW): 110 at 1 kV, 90 at 415 Volt, 132 at 690 Volt, AC3 Rating (Amps): 85 at 1000 Volt, 190 at 415 Volt, 135 at 690 Volt, AC1 Rating (Amps): 250 at 1 kV, 275 at 690 Volt, 1NO-1NC Auxiliary, 3 Pole, Operating Time: 25-60 ms Closing Delay, 45-80 ms Opening Delay, 196 mm Height, 105 mm Width, Without PLC Interface, Electronic Coil

Key Specifications

chevron-down
SKU
S&SCA919011120W
Brand
Sprecher+Schuh
Range Name
CA9
Product Type
Contactors Non-Reversing

Technical Specifications

chevron-down
Looking for something specific? Search with keywords to help filter your required specifications.
search close

Additional Information

Features
  • Simplifies selection with electronic wide range AC/DC coils
  • Saves energy with low power consumption
  • For ease of change over, adaptor plates available in KIT form for CA6 to CA9 migration
  • Several contactor families provide a wide variety of contactor sizes, offering economy and selection
  • Compact dimensions saves panel space
Standard Pack Size 1
UNSPSC Class 39121500
UOM EA
Vendor Product CA919011120W
AC1 Rating (Amps) 250/275 Amp AC1
AC3 Rating (Amps) 85/190/135 Amp AC3
AC3 Rating (kW) 110/90/132 kW
Contact Configuration 1 Normally Opened & 1 Normally Closed Aux
Height 196 mm
Number Of Poles 3 Pole
Operating Coil Voltage 100-250 Volt AC/DC
Operating Time 25-60 ms Closing/45-80 ms Opening
Please Note Without PLC Interface, Electronic Coil
Width 105 mm
