SAL LED Driver Constant Current Dimmable 18W 240V IP20

chevron-left

Description

chevron-down
LED Driver Constant Current Dimmable, Input Voltage: 240 Volt AC, Output Voltage: 20-40 Volt DC, 18 Watt, 500 mA, Dimmable, IP20, Power Factor: 0.9, 40 deg C, 121 mm Length, 45 mm Width, 20 mm Height

Key Specifications

chevron-down
Barcode (EAN-13)
9328623068049
SKU
SALDIM500MA/18W
Brand
SAL
Product Type
Drivers

Technical Specifications

chevron-down
Looking for something specific? Search with keywords to help filter your required specifications.
search close

Additional Information

Features
  • SELV and EMC compliant
  • Safe no load operation
  • Overload and short circuit protection
  • Dimmable with trailing edge dimmer, dimming range 10%~100%
  • The perfect choice for constant current electronic lighting circuits
Standard Pack Size 1
UNSPSC Class 39101900
UOM EA
Vendor Product DIM500MA/18W-NLA
Current 500 mA
Dimmable Dimmable
Height 20 mm
Input Voltage 240 Volt AC
IP Rating IP20
Output Voltage 20-40 Volt DC
Power Factor 0.9
Temperature 40 deg C
Wattage 18 Watt
Width 45 mm
