Serveredge Fibre Optic Distribution Riser Cable Singlemode OS2 24 Fibre LSZH Yellow

Description

Fibre Optic Distribution Riser Cable Singlemode, Fibre Optic Riser Cable 24 Core Single Mode OS2, ? 0.4 dB/km at 1310 nm, ? 0.3 dB/km at 1550 nm Attenuation, Long Term: 184mm, Short Term: 92mm Bend Radius, Fibre Count: 24, OS2 Fibre, Single Mode Fibre, During Installation: 450 N, During Operation: 250 N Tensile Strength, Strength Member: Aramid Yarn, LSZH Sheath, Yellow Sheath, Natural Fibre, Tight Coating: LSZH, 900 micron Nominal,-20 to 70 deg C, 9.2 ± 0.5mm Outside Diameter

Key Specifications

SKU	SEVPTR-24C-OS2
Brand	Serveredge
Product Type	Fibre Optic Riser

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Low smoke, zero halogen jacket High performance components and construction Complies with relevant ITU, IEC, standards & specifications High strength to weight ratio allows for easy handling Aramid yarn strength member and all dielectric cable construction 900 um buffer eliminates the need for costly and time consuming fan-out kits or pigtail splices because connectors terminate directly to the fibre Cable materials are indoor/outdoor - UV, water and fungus resistant
Standard Pack Size	1
UNSPSC Class	43223300
UOM	MTR
Vendor Product	PTR-24C-OS2
Attenuation	? 0.4 dB/km at 1310 nm/? 0.3 dB/km at 1550 nm
Bend Radius	Long Term: 184mm/Short Term: 92mm
Fibre Count	24
Fibre Mode	Single Mode
Fibre Type	OS2
Outside Diameter	9.2 ± 0.5mm
Sheath Colour	Yellow
Sheath Material	LSZH
Temperature	-20 to 70 deg C
Tensile Strength	During Installation: 450 N/During Operation: 250 N
Strength Member	Aramid Yarn
Tight Coating	LSZH/900 micron Nominal
