Siba Fuse Link UR Flush End Square Body 900A 690V 200kA Class aR Size 3
Description
Fuse Link UR Flush End Square Body, 690 Volt, 900 Amp, Flush End Connection, Square, 200 kA Interrupt Capacity, Class aR, 111mm Height x 88mm Width x 73mm Depth, Size 3
Key Specifications
| SKU |
SIB2068132-900
|
|---|---|
| Brand |
Siba
|
| Product Type |
Fuse Links
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 3 |
|---|---|
| UNSPSC Class | 39121600 |
| UOM | EA |
| Vendor Product | 2068132-900 |
| Connection Type | Flush End |
| Dimensions | 111 mm Height x 88 mm Width x 73 mm Depth |
| Interrupt Capacity | 200 kA |
| Standard Reference | Size 3 |
| Current | 900 Amp |
| Utilisation Category | Class aR |
| Voltage | 690 Volt |
