Siemens Protoflex Flexible Control Cable Unscreened 12 Core 2.5mm Copper 300/500V V-75 PVC/PVC Grey

Description

Flexible Control Cable, 2.5 mm, Stranded Copper, 300-500 Volt, 12 Core, 50/0.25 mm Strands, 15.2 mm Overall Diameter, Static 60.8 mm Flexible 114 mm Bend Radius, Static 50 N/mm Flexible 15 N/mm Tensile Strength, Black/Green/Yellow Core, V-75 PVC Insulation, PVC Sheath, Grey Sheath, Static -40 to 70 deg C Flexible -5 to 70 deg C, DIN VDE 7042 DIN VDE 047 IEC 033-1-2 AS 5000 DIN VDE 0281-13

Key Specifications

SKU	SIE5DE7165
Brand	Siemens
Product Type	Flexible Control Cable

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	500
UNSPSC Class	26121600
UOM	MTR
Vendor Product	5DE7165
Bend Radius	Static 60.8 mm - Flexible 114 mm
Core Colours	Black/Green/Yellow
Conductor Size	2.5 mm
Conductor Type	Stranded Copper
Insulation Material	V-75 PVC
Number of Cores	12 Core
Overall Diameter	15.2 mm
Sheath Colour	Grey
Sheath Material	PVC
Standards	DIN VDE 7042 DIN VDE 047 IEC 033-1-2 AS 5000 DIN VDE 0281-13
Stranding	50/0.25 mm
Temperature	Static -40 to 70 deg C Flexible -5 to 70 deg C
Tensile Strength	Static 50 Nm - Flexible 15 Nm
Voltage	300-500 Volt
