Socomec Load-Break Switch With Visible Contacts Front Operated 3P 160A AC21 75 kW AC23 Surface Mount IP65

$Socomec\Socomec_SIRCO_MV.jpg$

Description

Load-Break Switch With Visible Contacts Front Operated, 415 Volt AC, 160 Amp, AC21 Rating: 160 Amp, AC23 Rating: 160 Amp, 75 kW, 3 Pole, IP65, Surface Mount

Key Specifications

Barcode (EAN-13)	9321807196705
SKU	SOCVLB1603P
Brand	Socomec
Range Name	SIRCO MV
Product Type	Load-Break Switches

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Double break per pole offers high durability and short-circuit withstand Use of glass fibre reinforced polyester provides high mechanical and thermal resistance (does not include SLBM or VLBM modular series) Quick and easy to install thanks to good centre to centre distance and connection accessories including copper connecting links Wide range of accessories available which is flexible in adapting to various applications and reduces the cost of management and storage All Socomec load break switches are compatible with the ergonomic IP65 S-Type Handles which features interlocking (in the ON position), padlocking, UV and chemical agent resistive material and the choice of standard blue or red / yellow colour
Standard Pack Size	1
UNSPSC Class	39122200
UOM	EA
Vendor Product	VLB1603P
AC23 Rating	160 Amp 75 kW
Current	160 Amp
IP Rating	IP65
Number Of Poles	3 Pole
Voltage	415 Volt AC
