SMA Sunny Tripower Solar Inverter 2 MPPT Three Phase 5kW
Description
Key Specifications
SKU |
SSTSTP5.0-3AV-40
|
---|---|
Brand |
SMA
|
Range Name |
Sunny Tripower
|
Product Type |
Inverters
|
Technical Specifications
Additional Information
Features |
|
---|---|
Standard Pack Size | 1 |
UNSPSC Class | 26111600 |
UOM | EA |
Vendor Product | STP5.0-3AV-40 |
AC Max. Apparent Power | 5000 VA |
AC Nominal Voltage | 220-415 Volt-3/N/PE |
AC Operating Frequency | 50 Hz |
AC Operating Voltage | 180-280 Volt |
AC Output Current | 3 x 7.6 Amp |
AC Output Power | 5 kW |
Communication Port | WLAN/Ethernet/RS485 |
Climate Category | 4K4H |
Connection Type | SUNCLIX/AC Connector |
Cooling Method | Convection |
DC Input Power | 9000 Watt |
DC Input Voltage | 850 Volt |
DC Max. Input Current | 12 Amp |
DC MPPT Voltage Range | 215-800 Volt |
DC Nominal Voltage | 580 Volt |
DC Start-up Voltage | 175 Volt |
Depth | 176 mm |
Display Type | Smartphone/Tablet/Laptop |
Efficiency | 98.20% |
European Weighted Efficiency | 97.40% |
IP Rating | IP65 |
Height | 470 mm |
Noise Level | 30 dBA |
Number of MPPTs | 2 |
Operating Temperature | -25 to 60 deg C |
Phase | 3 Phase |
Power Factor | 1/Adjustable-0.8 Overexcited to 0.8 Underexcited |
Relative Humidity | 100% |
Topology | Transformerless |
Width | 435 mm |
