Schneider TeSys Model D General Purpose AC Operated Contactor 240VAC Coil 1NO+1NC Aux 15kW 32A AC3 50A AC1 3 Pole

Description

General Purpose AC Operated Contactor, 240 Volt AC Operating Coil, 1NO and 1NC Auxiliaries, AC3 Rating (kW): 15 kW, AC3 Rating (Amps): 32 Amp, AC1 Rating (Amps): 50 Amp, 3 Pole, 4 to 19 msec Opening/12 to 22 msec Closing Operating Time, Screw Clamp Terminal, IP20, DIN Rail Mounting, -5 to 60 deg C, 85 mm Height, 45 mm Width, 92 mm Depth, Safety Cover

Key Specifications

Barcode (EAN-13)	3389110351729
SKU	TEELC1-D32U7
Brand	Schneider
Range Name	TeSys Model D
Product Type	Contactors General

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	39121500
UOM	EA
Vendor Product	LC1D32U7-NLA
AC1 Rating (Amps)	50 Amp AC1
AC3 Rating (Amps)	32 Amp AC3
AC3 Rating (kW)	15 kW
Contact Configuration	1 Normally Opened & 1 Normally Closed Aux
Depth	92 mm
Height	85 mm
Mounting Method	DIN Rail
Number Of Poles	3 Pole
Operating Time	4 to 19 msec Opening 12 to 22 msec Closing
Please Note	Safety Cover
Temperature	-5 to 60 deg C
Terminal Connection	Screw Clamp
Width	45 mm
