Terasaki Combination RCD Circuit Breaker RCBO 1P+ N 16 Amp 240V AC 10 kA 2Module 36mm DIN 35 Rail

Description

Residual Current Device, 240 Volt, 16 Amp, 50/60 Hz, 10 kA Interrupt Capacity, 30 mA Trip Sensitivity, C Curve, 1 + N Pole, 2 Module 36 mm, 1-16 sq-mm/1-25 sq-mm Flexible/1-25 sq-mm/1-35 sq-mm Rigid Terminal, Pin/Fork Connection, IP20/40, DIN Rail Mounting, 5 to 55 deg C, 86 mm Height, 36 mm Width, 68 mm Depth

Key Specifications

Barcode (EAN-13)	5413656073260
SKU	TERDSRCB1630A
Brand	Terasaki
Range Name	Din-Safe

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Non-pigtail model with switched neutral Pigtail model with unswitched neutral 30 mA sensitivity for general personnel protection applications 10 mA sensitivity option for higher risk applications C trip curve for general light and power applications Fast connection pin/fork bus bar comb Suits pole-covers, loadcentres and the Conecpt range of panelboards
Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	DSRCB1630A-NLA
Current	16 Amp
Connection Type	Pin/Fork
Height	86 mm
Depth	68 mm
Modules	2 Module 36 mm
Frequency	50/60 Hz
Interrupt Capacity	10 kA
Mounting Method	DIN Rail
IP Rating	IP20/40
Number Of Poles	1 Pole
Temperature	5 to 55 deg C
Trip Characteristic	C Curve
Terminal Connection	1-16 sq-mm / 1-25 sq-mm Flexible / 1-25 sq-mm / 1-35 sq-mm Rigid
Trip Sensitivity	30 mA
Voltage	240 Volt
Width	36 mm
