Terasaki Moulded Case Circuit Breaker Thermal Magnetic 3 Pole 36 kA Icu 36 kA Ics 63 Amp Front Mount
Description
Moulded Case Circuit Breaker, 690 Volt AC, 63 Amp, 50/60 Hz, Interrupt Capacity: 36 kA Icu 36 kA Ics, Number of Poles: 3, Thermal Setting: 40-63 Amp Adjustable, Magnetic Setting: 378 to 756 Amp Adjustable, 125 AF Frame, Thermal Magnetic Trip, Front, 155mm Height x 90mm Width x 68mm Depth
Key Specifications
| Barcode (EAN-13) |
9321807198730
|
|---|---|
| SKU |
TERS125NJ363
|
| Brand |
Terasaki
|
| Range Name |
TemBreak 2 S125NJ
|
| Product Type |
MCCBs
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 1 |
|---|---|
| UNSPSC Class | 39121600 |
| UOM | EA |
| Vendor Product | S125NJ363 |
| Current | 63 Amp |
| Depth | 68 mm |
| Frame Type | 125 AF |
| Frequency | 50/60 Hz |
| Height | 155 mm |
| Interrupt Capacity | 36 kA Icu / 36 kA Ics |
| Magnetic Setting | 378 to 756 Amp Adjustable |
| Mounting Method | Front |
| Number Of Poles | 3 Pole |
| Thermal Setting | 40-63 Amp Adjustable |
| Trip Type | Thermal Magnetic |
| Voltage | 690 Volt |
| Width | 90 mm |
