Terasaki Combination RCD Circuit Breaker RCBO 4Pole 63 Amp 525V AC 25 kA 120mm Base
Description
Combination RCD Circuit Breaker RCBO, 63 Amp, 525 Volt AC, 50/60 Hz, Interrupt Capacity: 25 kA, Trip Sensitivity: 30 mA, Number of Poles: 4, 120mm Module Width, Base, 155mm Height, 120mm Width, 68mm Depth
Key Specifications
| SKU |
TERZS125GJ463
|
|---|---|
| Brand |
Terasaki
|
| Range Name |
TemBreak ZS
|
| Product Type |
Combination RCBO
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 1 |
|---|---|
| UNSPSC Class | 39121600 |
| UOM | EA |
| Vendor Product | ZS125GJ463 |
| Current | 63 Amp |
| Height | 155 mm |
| Depth | 68 mm |
| Modules | 120 mm |
| Frequency | 50/60 Hz |
| Interrupt Capacity | 25 kA |
| Mounting Method | Base Plate |
| Number Of Poles | 4 Pole |
| Trip Sensitivity | 30 mA |
| Voltage | 525 Volt |
| Width | 120 mm |
