Wilco Switch Socket Outlet Surface Mounting Metal Clad 1Ph 10A 250V 3 Pin Flat Yellow/Blue Switch IP66

Description

Switched Socket Outlet, 250 Volt, 10 Amp, 50 Hz, 1 Phase Phase, 2 Pole, 3 Pin Flat, Screw Connection, 1.5-6 sq-mm Terminal Capacity, Surface Mounting, IP66, Aluminium, Yellow/Blue, -25 to 75 deg C, 201 mm Height, 99 mm Width, 116 mm Depth

Key Specifications

Barcode (EAN-13)	9311554122669
SKU	WILWMC310
Brand	Wilco
Product Type	Switch Sockets

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Spring loaded socket flap with latch for added safety coverage Off and On marking is raised to ensure marking never wears off Padlocking facility (8 mm) in off position Optional safety interlock facility External and accessible mounting facilities 316 stainless steel cover mounting screws
Standard Pack Size	1
UNSPSC Class	39121400
UOM	EA
Vendor Product	WMC310
Colour	Yellow/Blue
Connection Type	Screw
Current	10 Amp
Depth	116 mm
Frequency	50 Hz
Height	201 mm
IP Rating	IP66
Material	Aluminium
Mounting Method	Surface
Number Of Poles	2 Pole
Phase	1 Phase
Pin Configuration	3 Pin Flat
Temperature	-25 to 75 deg C
Terminal Capacity	1.5-6 sq-mm
Voltage	250 Volt
Width	99 mm
