Winaico Solar Panel 585W Monocrystalline 144 Cells 44.22V 13.23A Silver Anodised Aluminum Residential 52.16V 13.85A 30A

$Winaico\Winaico_WST-530NGX-D3.JPG$

Description

Solar Panel, Residential Model, Monocrystalline Cell, 144, 585 Watt, 44.22 Volt Maximum, 13.23 Amp Maximum, 52.16 Volt Open Circuit, 13.85 Amp Short Circuit, 30 Amp Max. Fuse, 1500 Volt Max. System, 22.6% Efficiency, 0-5 Watt Power Tolerance, 2 x 1400 mtr, 4 sq-mm Output Cables, 2278 mm Length

Key Specifications

SKU	WINWST-585NGX72-A7
Brand	Winaico
Product Type	Solar Panels

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Better low-light performanceEnhanced electricity productionin low-irradiance environments PID & LID ResistantTo reduce power degradationand ensure long-term sustainedperformance Excellent durability in extremeenvironmentsWINAICO modules are testedabove and beyond internationalstandards.
Standard Pack Size	1
UNSPSC Class	26111600
UOM	EA
Vendor Product	WST-585NGX72-A7
Max. Fuse Current	30 Amp
Cell Type	Monocrystalline
Connector Type	PV-KST4-EVO2/xy_UR (M); PV-KBT4-EVO2/xy_UR (F) IP68
Certifications	IEC 61215:2021 / IEC 61730:2023 / ISO 9001 / ISO 5000 / ISO 1400
Efficiency	22.60%
Frame Construction	Silver Anodized Aluminium
Front Glass	2 mm, Semi-Tempered Solar Glass with Anti-Reflective Coating
Height	35 mm
Junction Box	IP68 / 3 Bypass Diodes
Item Weight	32.7 kg
Max. Current	13.23 Amp
Max. Fuse Current	30 Amp
Max. System Voltage	1500 Volt
Number Of Cells	144
Model	Residential
Operating Temperature	-40 to 85 deg C
Output Cables	2 x 1400 mtr / 4 sq-mm
Power Tolerance	0-5 Watt
Short Circuit Current	13.85 Amp
Temperature Coefficient	-0.29%/ deg C
Warranty	15 Years Product / 30 Years Performance
Wattage	585 Watt
Width	1134 mm
